Parameter Setup

5.1.9
The drive can be used for practically all assignments. The drive offers 2 programming modes:
Main menu mode
l
Quick menu mode
l
Main menu mode provides access to all parameters.
Quick menu mode enables operation of the drive by setting only a few basic parameters.
Parameters can be changed in either main menu mode or quick menu mode.
5.1.10

Quick Menu Key Functions

Press [Quick Menu] to enter a list of different areas contained in the Quick Menu.
40.0%
Quick Menu
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Figure 15: Quick Menus
Select Q1 My Personal Menu to show the selected personal parameters. These parameters are selected in parameter 0-25 My Personal
Menu. Up to 50 different parameters can be added in this menu.
Select Q2 Quick Setup to go through a selection of parameters to get the motor running almost optimally. The default settings for the
other parameters consider the required control functions and the configuration of signal inputs/outputs (control terminals).
Parameters are selected via the navigation keys. The parameters in
Table 5: Selection of Parameter
Parameter
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
Parameter 1-28 Motor Rotation Check
Parameter 3-41 Ramp 1 Ramp Up Time
Parameter 3-42 Ramp 1 Ramp Down Time
34 | © 2024.10
4.84 A 1(1)
are accessible.
Table 5
Setting
Select the language. Default is [0] English.
[kW]
[V]
[Hz]
[A]
[RPM]
[Hz]
[s]
[s]
How to Program
AU430028034214en-001901 / 130R0310
