Programming Guide | VLT® HVAC Drive FC 102
Data type: Uint8
Select the operator to be used in the comparison. This is an array parameter containing comparator operators 0–5.
Option Name
[0] <
≂ (equal)
[1]
[2] >
[5] TRUE longer than..
[6] FALSE longerthan..
[7] TRUE shorter than..
[8] FALSE shorter than..
13-12 Comparator Value
Default value: Size related
Setup:
2 setups
Data type: Int32
Enter the trigger level for the variable that is monitored by this comparator. This is an array parameter containing comparator values 0–9.

13-1* RS Flip Flops

6.15.4
The reset/set flip flops hold the signal until set/reset.
© 2024.10
Change during operation:
Description
If [20] Alarm number or [21] Warning number is selected
in parameter 3-10 Comparator Operand, [0] < cannot be
selected in this parameter.
The result of the evaluation is true when the variable selected in
parameter 13-10 Comparator Operand is smaller than the fixed
value in parameter 13-12 Comparator Value. The result is false if
the variable selected in parameter 13-10 Comparator Operand
is greater than the fixed value in parameter 13-12 Comparator
Value.
The result of the evaluation is true when the variable selected in
parameter 13-10 Comparator Operand is approximately equal to
the fixed value in parameter 13-12 Comparator Value.
If [20] Alarm number or [21] Warning number is selected
in parameter 3-10 Comparator Operand, [2] > cannot be
selected in this parameter.
Inverse logic of option [0] <.
Parameter type:
Conversion index:
Change during operation:
AU430028034214en-001901 / 130R0310 |
Parameter Descriptions
True
NOTICE
NOTICE
Range, -10000.000 - 100000,
Array [10]
-3
True
