Programming Guide | VLT® HVAC Drive FC 102
[9]: Fan power card 1 (optional).
l
[10]: Fan power card 2 (optional).
l
43-00 Component Temp.
Default value:
0 °C
Setup: All setups
Data type: Int8
Shows the temperature of a system component. The elements of the array reference local PCB temperature sensor measurements.
Parameter 16-31 System Temp uses all elements in this array to calculate the system temperature.
43-01 Auxiliary Temp.
Default value: 0 °C
Setup:
All setups
Data type: Int8
Shows the temperature of an auxiliary component. The elements of the array reference the temperature measurements from the NTC
temperature sensors connected to hardware components in the drive. Refer to the Operating Guide for specifications of temperature
sensor placement.
43-02 Component SW ID
Default value:
0
Setup: All setups
Data type:
VisStr[18]
Shows the software version of the installed option.
6.33.2 43-1* Power Card Status
This parameter group contains read-only information on hardware components in the power section. All parameters in this group are
arrays:
[0]: Power card 1 (the master power card in a parallel drive, or the only power card in a drive with a single inverter section).
l
[1]: Power card 2 (inverter connection in a parallel drive).
l
[2]: Power card 3 (inverter connection in a parallel drive).
l
[3]: Power card 4 (inverter connection in a parallel drive).
l
[4]: Power card 5 (rectifier connection in a parallel drive).
l
[5]: Power card 6 (rectifier connection in a parallel drive).
l
[6]: Power card 7 (rectifier connection in a parallel drive).
l
[7]: Power card 8 (rectifier connection in a parallel drive).
l
43-10 HS Temp. ph.U
Default value: 0 °C
Setup:
All setups
Data type: Int8
© 2024.10
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
AU430028034214en-001901 / 130R0310 |
Parameter Descriptions
Range, -128 - 127 °C, Array [18]
100
True
Range, -128 - 127 °C, Array [18]
100
True
Range, 0 - 20, Array [18]
0
True
Range, -128 - 127, Array [8]
100
True
