Programming Guide | VLT® HVAC Drive FC 102
Set the output frequency transferred to output terminal 29 when the terminal is configured as [48] Bus Ctrl Timeout in parameter 5-63
Terminal 29 Pulse Output Variable and a timeout is detected.
5-97 Pulse Out #30/6 Bus Control
Default value: 0%
Setup: All setups
Data type: N2
Set the output frequency transferred to output terminal X30/6 when the terminal is configured as [45] Bus ctrl. in parameter 5-66
Terminal X30/6 Pulse Output Variable.
5-98 Pulse Out #30/6 Timeout Preset
Default value:
0%
Setup: 1 setup
Data type:
Uint16
Set the output frequency transferred to output terminal X30/6 when the terminal is configured as [48] Bus Ctrl Timeout in parameter
5-66 Terminal X30/6 Pulse Output Variable and a timeout is detected.

Parameter Group 6-** Analog In/Out

6.8

6-0* Analog I/O Mode

6.8.1
The analog inputs can be allocated to either voltage (0–10 V) or current input (0/4–20 mA).
Thermistors may be connected to either an analog or a digital input.
6-00 Live Zero Timeout Time
Default value:
10 s
Setup: All seutps
Data type: Uint8
Enter the live zero timeout in s. Live zero timeout time is active for analog inputs, that is terminal 53 or terminal 54, used as reference or
feedback sources. If the reference signal value associated with the selected current input drops below 50% of the value set in:
Parameter 6-10 Terminal 53 Low Voltage
l
Parameter 6-12 Terminal 53 Low Current
l
Parameter 6-20 Terminal 54 Low Voltage
l
Parameter 6-22 Terminal 54 Low Current
l
for a time period longer than the time set in parameter 6-00 Live Zero Timeout Time, the function selected in parameter 6-01 Live Zero
Timeout Function is activated.
6-01 Live Zero Timeout Function
Default value: [0] Off
Setup: All setups
© 2024.10
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Changing during operation:
NOTICE
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Parameter Descriptions
Range, 0 - 100%
-2
True
Range, 0 - 100%
-2
True
Range, 1 - 99 s
0
True
Option
–
