Programming Guide | VLT® HVAC Drive FC 102
Option Name
[2] Trip
[3] Trip lock
[4] Trip w. delayed reset
Table 43: Possible Actions when Selected Alarms Appear
Failure Parameter
10 V low 1490.0
24 V low 1490.1
1.8 V low 1490.2
Voltage limit 1490.3
Ground fault 1490.4
during ramp-
ing
Ground fault 1490.5
2 during con-
tinuous oper-
ation
Torque limit 1490.6
Overcurrent 1490.7
Short circuit 1490.8
Heat sink 1490.9
temp.
Heat sink sen- 1490.10
sor
Control card 1490.11
temp.
Power card 1490.12
temp.
© 2024.10
Alarm Off
(1)
1 X
47 X
48 X
64 X
14 –
45 –
12 X
13 –
16 –
29 –
39 –
65 –
69 –
Description
Changing a fault level from default option [3] Trip Lock to [2] Trip
leads to the automatic reset of the alarm. For alarms involving
overcurrent, the drive has a hardware protection that issues a 3-
minute recovery after 2 consecutive overcurrent incidents. This
hardware protection cannot be overruled.
This option adds a delay between automatic resets, otherwise
it is the same as option [2] Trip. The delay prevents a situation
where reset is attempted repeatedly for an overcurrent situation.
Hardware protection of the drive forces the 3-minute recovery
time after 2 consecutive overcurrents (within a short time
window).
Warning Trip
(2)
D –
– –
– –
D –
– D
– D
D –
– –
– X
– X
– X
– X
(3)
X
AU430028034214en-001901 / 130R0310 |
Parameter Descriptions
Trip lock Trip with
delayed reset
– –
D –
D –
– –
X –
X –
– –
D X
D –
D –
D –
D –
D –
383
