3. Press [▲] and [▼] to scroll down to Function Setups.
69.3%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made

The Function Setups options appear
4.
Select Q3-1 General Settings and press [OK].
28.4%
Function Setups
Q3-1 General Settings
Q3-2 Open Loop Settings
Q3-3 Closed Loop Settings
Q3-4 Application Settings
5. Press [▲] and [▼] to scroll down to Q3-11 Analog Outputs and press [OK].
26.0%
General Settings
Q3 - 10 Adv. Motor Settings
Q3 - 11 Analog Output
Q3 - 12 Clock Settings
Q3 - 13 Display Settings
6. Select parameter 6-50 Terminal 42 Output and press [OK].
