Operating Examples
2 58
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Do the following three steps to create the sequence.
13. Create line 0 and line 1 in the sequence.
Menu button Bottom button
Select the SUB1 from the Select block and Sub sequence popup menu using the front
panel knob.
With the front panel down arrow button, advance the line pointer to the next line.
Using above procedures, insert SUB1 into the line 1 and set the Trig Wait.
14. Create line 2 and line 3. Note that you can not set the jump address (line
number) that has not been created. The jump condition is set in step
Menu button Bottom button
Select the BK1 from the Select block and Sub sequence popup menu using the front
panel knob.
With the front panel down arrow button, advance the line pointer to the next line.
Using above procedures, insert BK4 into the line 3.
Popup menu Side button
Insert
OK
Set Enhanced
Control
Trig Wait
(Set to On)
Go Back
Popup menu Side button
Insert
OK
Set Enhanced
Control
Repeat Count
(Set to Infinite)
Go Back
Front panel
button
Front panel
button
