DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Fuse
0.25 inch × 1.25 inch (UL 198G,3AG) : 6A
FAST, 250 V
5 mm × 20 mm (IEC 127) : 5A (T), 250 V
NOTE. The second fuse listed in the table above is approved under the IEC
standards. This fuse is used in equipment sold in the European market.
4. Check that you have the proper electrical connections. The DG2030 operates
within the following power supply voltage and frequency ranges:
Line voltage range
Line frequency
Maximum power
CAUTION. The DG2030 is shipped with a power cord appropriate for use with
normal 115 V power systems. If the DG2030 is to be used with 230 V power, the
power cord must be replaced with one appropriate for the power source used.
See Table 1-4, Power cord identification, for the available power cord types.
5. Connect the proper power cord from the rear panel power connector to the
power system.
Getting Started
Fuse cap
part number
Fuse part number
159 0239 XX 200 2264 XX
159 0210 XX 200 2265 XX
90 V - 250 V
48 Hz - 440 Hz (90 V - 127 V)
48 Hz - 63 Hz (127 V - 250 V)
300 W
1 7
