Edit Menu
Binary Up Counter
Johnson Counter
Figure 3 36: Standard pattern data
3 42
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Operation. Creating the standard pattern data
Bottom button Popup menu
Set the editing range in the point direction.
Set the editing range in the group/bit direction.
Execute Action Select from the following items.
Binary up counter
Binary down counter
Johnson counter
Graycode counter
Binary Down Counter
Graycode Counter
Side button
OK
