Operating Examples
2 38
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
b. Set the glitch width to be 1.
Menu Button Bottom Button
Move the knob icon to the Width window in the upper left of the screen by pressing the
front panel CURSOR button once or twice.
c. Select invert as the edit operation.
Menu Button Bottom Button
Execute
Action
d. Insert two glitches.
Menu Button Bottom Button
Move the knob icon to the Cursor window in the upper left of the screen by pressing the
front panel CURSOR button once.
This step inserted glitches at the points for cursor positions 32 and 96.
Figure 2-23 shows the pattern edited in example 2.
Popup Menu Side Button
Popup Menu Side Button
Invert data OK
Popup Menu Side Button
Front Panel
Button
1
ENTER
Front Panel
Button
Front Panel
Button
32
ENTER
EXECUTE
96
ENTER
EXECUTE
