Operating Examples

Example 2: Loading and Editing a Pattern Stored in a File

Reading the File
2 36
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Example 2 loads a file from a floppy disk, and demonstrates pattern editing
using that data.
Before loading a file from the floppy disk, initialize the instrument's data and
settings. This allows you to see the effect of loading the file you previously
saved in example 1.
1. Clear the data group and data definitions.
Menu Button Bottom Button
SETUP Group Assign
EDIT File
2. Read in the file created in example 1 from the floppy disk.
a. Insert the floppy disk in the instrument's floppy disk drive.
b. Execute the following actions.
Menu Button Bottom Button
EDIT File
Select the file COUNT1.PDA from the file list using the general purpose knob.
This loads the pattern created in example 1.
Popup Menu Side Button
Reset All bits
Assign
OK
New
OK
Popup Menu Side Button
Load Data &
Setup
OK
Front Panel
Button
Front Panel
Button
