c. Attach the name IC1 to the newly created group.
Menu button Bottom button
2. Assign DATA4 to DATA7 to a group called IC2.
a. Set the MSB and LSB.
Menu button Bottom button
NOTE. The MSB setting may change depending on the direction the general
purpose knob is turned. If that happens, the MSB setting must be set again.
b. Attach the name IC2 to the group.
Menu button Bottom button
Then you can see a display as shown in 2-24.
Popup menu Side button
Rename
Clear String
IC1 OK
Popup menu Side button
Select Group Bit(s)
0 DATA7 Config
MSB
(Set D7)
LSB
(Set D4)
OK
Popup menu Side button
Rename
Clear String
IC2 OK
Operating Examples
Front panel
button
Front panel
button
Front panel
button
2 41
