Edit Menu
Table 3 1: EDIT menu functions (Cont.)
Bottom
Execute Action
Enhanced Action
3 6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Base or side menu
Set scope
Cut
Copy
Paste insert
Paste replace
Set data to high
Set data to low
Insert high data
Insert low data
Invert data
Mirror vertical
Mirror horizontal
Magnify
Numeric input
Shift left (add zero) or
Shift right (add zero)
Shift left or Shift right
Shift up (add zero) or
Shift down (add zero)
Shift up or Shift down
Rotate left or Rotate right
Rotate left or Rotate right
Binary up counter
Binary down counter
Johnson counter
Graycode counter
Clock Pattern
Shift Register Generator
Logical Operation
Bit Operation
Serial Code Converter
Function
Setting the scope
Deleting pattern data
Copying pattern data
Pasting (inserting) pattern data
Pasting (replacing) pattern data
Setting pattern data to high
Setting pattern data to low
Inserting high data
Inserting low data
Inverting data
Swapping pattern data in the vertical direction
Swapping pattern data in the horizontal direction
Magnifying pattern data
Inputting pattern data numerically
Shifting pattern data left or right by inserting zeros
Shifting pattern data left or right
Shifting pattern data up or down by inserting zeros
Shifting pattern data left or right
Rotating pattern data left or right
Rotating pattern data up or down
Creating standard pattern data
Clock pattern generation
Pseudorandom pulse generation
Logical operations between pattern data items
Moving or copying pattern data
Serial code data conversion
