Item Function
Set All Registers Sets the value of all the register bits to 1.
Maximum Length Tap Sets the taps to positions such that the output becomes a tap M series
for the current register length. There are multiple tap combinations for
M series bit series. Each time the Maximum Length Tap button is
pressed, the tap combination changes.
Region The values All and Entered can be set. When All is selected, all of the
Dest Bit memory is filled with the pseudo random pulse pattern. When
Entered is selected, the pattern is written to the area specified by the
From and Size parameters.
Operation. Set the register value input and taps
Bottom button Popup menu
Enhanced Action Shift Register Generator
Set the parameters in the popup menu.
(Register Length, Points/Step, Dest Bit, From, Size)
Use the general purpose knob to select bits for setting in the register.
Set the value of a bit in the register with the 0 and 1 numeric keys.
Set the tap on/off state for a bit using the -" numeric key.
Edit Menu
Side button
OK
Region (Select All or
Entered)
OK
