Appendix B: Performance Verification
B 30
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4. Confirm the high voltage level as following procedures:
a. Press the STEP/EVENT button on the DG2030 front panel once to
output high voltage level.
b. Set the high and low voltage levels to the values indicated in Table B-5,
and confirm that the digital multi–meter reading for each high voltage
level setting falls within the specified voltage range.
c. Repeat step b for all high and low voltage settings in Table B-5.
d. Repeat steps from a to c for all output channels from CH0 to CH3 (or to
CH7 if the option 01 has been installed) as changing the BNC cable
connection.
Table B 5: High level output voltage accuracy
Settings
High voltage level (V) Low voltage level (V)
-1.25 -1.50
0 -1.50
+1.00 -1.50
+2.00 -1.50
+3.50 -1.50
5. Confirm the low voltage level as following procedures:
a. Press the STEP/EVENT button on the DG2030 front panel once to
output low voltage level.
b. Set the low and high voltage levels to the values as shown in Table B-6,
and confirm that the digital multi–meter reading for each voltage setting
falls within the specified voltage range.
c. Repeat step b for all high and low voltage settings in Table B-6.
d. Repeat steps from a to c for all output channels from CH0 to CH3 (or to
CH7 if the option 01 has been installed) as changing the BNC cable
connection.
High level output voltage ranges
-1.337 V to -1.163 V
-0.050 V to +0.050 V
+0.920 V to +1.080 V
+1.89 V to +2.11 V
+3.35 V to +3.65 V
