Table 3 18: Setup menu display
Screen
reference Function
1 Shows the pulse parameters set for a selected output channel
and frequency currently set.
2 Shows the method selected for data output high impedance
control.
3 Shows the settings of the raise and fall time for each channel.
As referring to the displayed pulse image, the raise and fall
time can be set for the pulse pattern on each channel.
4 Shows the output delays. Delays can only be set for each
output channel.
5 Shows the high and low values of the output voltage. These
voltages can be set to arbitrary values between -1.5 and 3 V.
6 Shows the data bits and the group to which each data bit
belongs.
7 Shows the output channel. The channels are labeled numbered
0 through 7.
Setup Menu
Page
3 73
3 70
3 73
3 75
3 72
3 66
-
3 65
