Operating Examples

Example 3: Signal Output

Grouping data bits
2 40
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Example 3 first groups the data bits from the pattern data created in example 2
and allocates each data bit to output channels. Next, this procedure sets all the
settings required for signal output and actually outputs the signals.
1. Assign DATA0 to DATA3 to a group called IC1.
a. Reset all bit allocations.
Menu button Bottom button
SETUP Group Assign
b. Set the MSB (most significant bit) and LSB (least significant bit) to D3
and D0, respectively.
Menu button Bottom button
NOTE. The MSB setting may change depending on the direction the general
purpose knob is turned. If that happens, the MSB setting must be set again.
Popup menu Side button
Reset All bits
Assign
OK
Popup menu Side button
Select Group Bit(s)
4 DATA3 Config
MSB
(Set D3)
LSB
(Set D0)
OK
Front panel
button
Front panel
button
