Operating Examples
Pattern Creation
2 34
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3. Set the data bit positions and bit widths. Here we will set the height (scope)
and width of the data we are going to edit.
Menu button Bottom button
Execute
Action
Move the knob icon to the Cursor window in the upper left of the screen by pressing the
front panel CURSOR button once or twice.
Move the knob icon to the Width window in the upper left of the screen by pressing the
front panel CURSOR button once.
Press the down arrow button until the area cursor covers DATA0 to DATA3.
4. Create the binary pattern for a value being incremented every 4 clock ticks.
Menu button Bottom button
Execute
Action
This creates the binary pattern shown in Figure 2-22 in DATA0 to DATA3.
Popup menu Side button
Set scope OK
4 OK
Popup menu Side button
Binary up OK
counter
OK
Front panel
button
0
ENTER
1024
ENTER
Front panel
button
4
ENTER
EXECUTE
