Sequence Data

Operating Modes Overview

Run Modes
DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The sequence data is a program that specifies the order in which the pattern data
is output. The sequence data is used to set up operations such as iteratively
putting out blocks of pattern data for a specified number of times, and jumping
to a specified block when an external event occurs. Sequences allow long
patterns to be set up without preparing large quantities of data.
Sequences can include other sequences (called subsequences) so that you can
make complex sequence program easier. Sequence data is transferred to the
pattern generation unit sequence memory, and controls the operation of the
pattern control circuit. Using the run mode, which is described in detail later, you
can select whether all the sequence data is valid or whether enhanced mode
settings such as event jumps in the sequence are ignored.
In the run modes, pattern output is controlled by the pattern generation unit's
pattern control circuit. The DG2030 supports four run modes: repeat, single,
step, and enhanced. These run modes are specified with the SETUP → Run
Mode menu. Table 2-3 provides functional information for each mode.
Table 2 3: Run modes
Run mode Function
Repeat Repeats the pattern data from the first to last data point indefinitely.
If a sequence is defined, iterates the output according to that
sequence.
Single Outputs the pattern data once from the first to last data point in point
order. If a sequence is defined, outputs the pattern once according to
that sequence.
Step Operates identically to repeat mode, except that just one data point
is output each time the STEP/EVENT button is pressed.
Enhanced Same as Repeat with the addition that event jumps and trigger waits
are also effective.
NOTE. The Repeat, Single, and Step modes ignore the event jump and trigger
wait settings.
Operating Basics
2 13
