Utility Menu

Hardcopy

3 92
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Sets the screen hard-copy data format settings, and sets the hard-copy output
port. For connecting the printer to the GPIB or RS-232-C port, also refer to the
System menu explained next. When you select Disk as a hardcopy port, you can
capture and save a screen image to a file in a specific format.
Base menu
Item Function
Format Sets the screen hard copy data format. The following are the menu
options and the formats they specify.
Menu item
BMP
Epson
EPS mono
Thinkjet
TIFF
Port Sets the device for screen hard copy data output.
Menu item
DISK
GPIB
RS232C
When hard copy output is to the disk, a file name with the format
HC_XXX.YYY is used. Here, XXX is a serial number that is started
from 000, and YYY is an extension that depends on the format used.
XXX is chosen so as not to overwrite existing data. The table below
lists the correspondence between formats and extensions.
Menu item
BMP
Epson
EPS mono
Thinkjet
TIFF
Format
Windows BMP
Epson ESC P
Encapsulated Postscript
HP Thinkjet
TIFF
Device
Floppy disk
GPIB
Serial port
Format Extension
Windows BMP BMP
Epson ESC P ESC
Encapsulated Postscript EPS
HP Thinkjet TJ
TIFF TIF
