File Menu

Load Data & Setup
Save Data & Setup
DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The File menu saves and loads data between the instrument's internal memory
and mass memory (floppy disks). When the File bottom menu item is selected, a
side menu with Load Data & Setup, Save Data & Setup, Import, Export, and
New items is displayed.
Reads format pattern data, block, group, sequence and setup data into the
instrument's internal memory from mass memory (floppy disk).
The DG2030 can read data created and stored from the DG2020. The DG2030
will use the pattern data in the lower 8 bits. Also, the DG2030 can read DG2020
setup information except for those settings that are not common to both
platforms.
Sub menu
Item Function
Change Directory Changes the current directory.
Operation. Load the pattern data and setup parameters.
Bottom button Popup menu
Insert a floppy disk in the floppy disk drive.
File
Select the file to be loaded.
Stores the pattern data, block, group, sequence and setup data from the instru-
ment's internal memory to mass memory (floppy disk) in DG2030 format.
Sub Menu
Item Function
Clear String Deletes the current displayed string.
Change Directory Changes the current directory.
Edit Menu
Side button
Load Data & Setup
OK
3 9
