Operating Examples
Preparing to Create Data
Creating 4 Blocks
2 50
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1. Clear the data group definitions and pattern data.
Menu button Bottom button
SETUP Group Assign
EDIT File
2. Set the length of pattern memory (the number of samples) to 512 points.
Menu button Bottom button
Settings
3. Set the block cursor position and width. This procedure sets a scope of 8
(DATA0 to DATA7) and a width of 128 samples.
Menu button Bottom button
Execute
Action
Move the knob icon to the Width window in the upper left of the screen using the front
panel CURSOR button.
4. Divide the data between block 1 (point 0 to 127) and block 2 (point 128 to
511). Use BK2 as the name for block 2.
Popup menu Side button
Reset All bits
Assign
OK
New
OK
Popup menu Side button
Set memory OK
size
OK
Popup menu Side button
Set scope OK
8 OK
Front panel
button
Front panel
button
512
ENTER
Front panel
button
128
ENTER
