Block Menu
DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
The block menu is used to define packets of data called blocks and the cursor
movement with respect to those blocks. The items to be set are selected from a
popup list using the general purpose knob.
Figure 3 12: Block popup menu
Block Relative Cursor Movement. Moves the cursor relative to the current block.
Table 3-7 provides a description for each item in the Block popup menu.
Table 3 7: Block relative cursor movement
Select item
Description
Move to block start
Moves the cursor to the start of the block in which the cursor is
currently located.
Move to block end
Moves the cursor to the end of the block in which the cursor is
currently located.
Move to next block
Moves the cursor to the start of the block following the block in
which the cursor is currently located.
Move to previous block
Moves the cursor to the start of the block preceding the block in
which the cursor is currently located.
Move to block (any)
Moves the cursor to the start of a block selected from a list of
blocks in a popup menu.
Edit Menu
3 25
