Appendix A: Specifications
Table A 6: Nominal traits electrical characteristics (Cont.)
Characteristics
Trigger input
Connector
Threshold level
Resolution
Impedance
Polarity
External clock input
Connector
Impedance
Display
Display area
Resolution
AC line power
Fuse rating
Table A 7: Nominal traits mechanical characteristics
Characteristics
Net weight
Standard
Dimensions
Height
Width
Length
A 12
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Description
BNC at front panel
-5.0 V to +5.0 V, +1.4 V at default
0.1 V
50 W or 1 kW
Positive or Negative
BNC at rear panel
50 W terminated to 0.5 V
Width: 13.2 cm (5.2 inches)
Height: 9.9 cm (3.9 inches)
Horizontal: 640 pixels
Vertical: 480 pixels
6A FAST, 250 V, UL 198G ( 3AG )
5A ( T ), 250 V, IEC 127
Description
10.3 kg (22.7 lb)
164 mm (6.4 inches) including feet
362 mm (14.3 inches) including handle
491 mm (19.25 inches) including front cover
576 mm (22.2 inches) with handle extended
