The following typographical conventions are used in this manual.
H Names of front panel controls and menu item names are in bold with the
same case (initial capitals or all upper case) as they appear on the unit itself.
For example, SETUP, Sub-sequence.
H Sections 2, 3, and Appendix B describe instrument functions by using a table
to list a sequence of steps. Each operating procedure is presented in order
starting with step 1, and progresses until the end of the procedures. Execute
the action in the top-left table entry first. Then execute actions from left to
right along each row. When you are done executing the steps in one row,
move to the left end of the next row down, and continue executing the listed
steps until the end of the table.
For pop-up menus, use the general-purpose knob to select items from the
menu list. Operations such as operation 6 (below) do not involve pressing
the buttons shown in the row above, but rather are descriptions of operations
to be performed.
Menu button Bottom button
Operation 1 Operation 2
Operation 6 (for example, 'Use the general purpose knob to set cursor field to 128.')
Popup menu Side button
Operation 3 Operation 4
Operation 7
Front panel
button
Operation 5
