Floppy Disk Drive
DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Figure 2-4 shows the floppy disk drive controls and indicators. The floppy disk
drive is located on the right side of the DG2030 chassis. You use the floppy disk
drive to save and recall instrument pattern and setting data.
CAUTION. Do not press the eject button while the DG2030 is writing to the
floppy disk. Doing so can cause data corruption on the floppy disk.
LED indicator
When the disk drive is in operation, the
LED indicator is lit.
Figure 2 4: Floppy disk drive
Operating Basics
Eject button
Remove a floppy disk by pressing the
eject button.
2 5
