Example 1: Creating a Pattern and Storing into a File

Preparation for Pattern
Creation
Environment Setup for
Pattern Creation
DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Example 1 creates the output pattern for an 4-bit binary counter and stores that
pattern into a floppy disk.
Before creating new pattern data, initialize the instrument's data and settings.
1. Clear the data group definitions and data memory.
Menu button Bottom button
SETUP Group Assign
EDIT File
2. Set the pattern memory length to 1024 points.
Menu button Bottom button
Settings
* Use the front panel keypad to enter numeric values.
Popup menu Side button
Reset All bits
Assign
OK
New
OK
Popup menu Side button
Set memory OK
size
OK
Operating Examples
Front panel
button
Front panel
button
1024 *
ENTER
2 33
