Menu button Bottom button
Using the same procedure to turn off the output impedance control for channels
CH1 to CH7.
c. Allocate the IC1 group data to the output channels CH0 to CH3. See
Figure 2-25.
Menu button Bottom button
Press the front panel up and down arrow buttons to select channel CH0 from the Output
assign list.
Select data D3 (IC1:3) from the Data bits list using the general purpose knob.
Allocate D2 to D0 to CH1 to CH3 using the same procedurel.
d. Allocate the IC2 group data to the output channels CH4 to CH7 in the
same way as step c.
NOTE. Press the OK button when done to activate the allocations. Note that the
allocations will not become valid unless the OK button is pressed.
Popup menu Side button
OK
Go Back
Popup menu Side button
Assign
Condition
Assign
OK
Operating Examples
Front panel
button
Front panel
button
2 43
