Edit Menu
3 54
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Sub Menu
Item Function
Insert Empty Line Inserts an empty line before the line currently indicated by the block
cursor.
Delete Line Deletes the line currently indicated by the block cursor.
Delete All Lines Deletes all lines in the table.
NOTE. The maximum size of the table data is 1024 lines.
Operation. The procedure for editing a code conversion table is as follows:The
four arrow buttons are used to move the cursor. The general purpose knob can
also be used for cursor movement. The CURSOR button causes the general
purpose knob to switch between controlling vertical and horizontal movement.
Use these procedures to move the cursor to the target location and then use the
numeric keys to edit the data. Table 3-16 lists the roles of the numeric keys.
Table 3 16: Numeric key description
Numeric Key Description
0 Sets the table data at the cursor to 0.
1 Sets the table data at the cursor to 1.
- Sets the table data at the cursor to the don't care state.
The delete key clears the table data in the area that contains the cursor.
Sometimes, data at positions other than the cursor position may be changed. For
example, pressing 0 or 1 near the center of the SOURCE CONDITION's
CURRENT field when the field is empty changes data from the start of that area
to the cursor position.
