Edit Menu

Rename Current Block

Resize Current Block

3 28
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Changes the name of the block at the current cursor position.
Operation. Change a block name
Bottom button Popup menu
Move the knob icon to the Cursor window in the upper left of the screen.
Move the cursor to the block whose name is to be changed.
Block Select Rename current block.
Enter the new block name.
Changes the size of the block at the current cursor position. The size of other
blocks is not changed; the memory size is changed.
When increasing the size of the current block, only set a size that does not cause
the total number of points to exceed the maximum memory size. Zero data
corresponding to the increase in size is added at the end of the block.
When decreasing the size of the current block, data is deleted from the end of the
block.
Note that the range of allowable block sizes starts at a minimum size of
90 points.
NOTE. Changing the block size cannot be reversed with the Undo operation.
Before Change a
Block 1
Block Size
After Change a
Block 1
Block Size
Figure 3 16: Change a block size
Current Cursor Position
Block 2 Block 3
Block 2 Block 3
90 Points or Over
Side button
OK
Clear String
OK
