Tektronix DG2030 User Manual page 72

Selecting Bits to Edit
Shifting Pattern
Inserting a Glitch
DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3. Select DATA4 and DATA5 as the area to be edited.
Menu Button Bottom Button
Execute
Action
Move the knob icon to the Cursor window in the upper left of the screen by pressing the
front panel CURSOR button once or twice.
Move the knob icon to the Width window in the upper left of the screen by pressing the
front panel CURSOR button once.
Press the up and down arrow buttons until the area cursor covers DATA4 and DATA5.
4. Do the following steps to shift the bits in DATA4 and DATA5 exactly one
sample width to the right.
Menu Button Bottom Button
Execute
Action
5. DO the following steps to insert a glitch with a width of 1 sample in the
DATA5 bits.
a. Set DATA5 as the bits that will be the object of the edit.
Menu Button Bottom Button
Execute
Action
Set the block cursor to cover DATA5 using the up and down arrow buttons.
Popup Menu Side Button
Set scope OK
2 OK
Popup Menu Side Button
Shift right OK
(add zero)
Popup Menu Side Button
Set scope OK
1 OK
Operating Examples
Front Panel
Button
0
ENTER
1024
ENTER
Front Panel
Button
EXECUTE
Front Panel
Button
2 37
