Operation. Enable or disable the event control
Bottom button Popup menu
Output Condition
Operation. Set the inhibit level
Bottom button Popup menu
Output Condition
Operation. Select an impedance state control method
Bottom button Popup menu
Output Condition
Select the channel to be set up for high impedance control with the up and down arrow buttons.
Select one of Off, Internal, External, and Both.
Table 3 19: Impedance state contol methods
Selection item Description
OFF No high impedance control (output is always enabled)
Internal Controlled by the channel 0 signal (high impedance when high)
External Controlled by an external impedance control signal (high impedance
when high)
Both Controlled by both the channel 0 and external impedance control
signals (high impedance when either signal is high)
Since the channel 0 signal for each output cannot control its own high-imped-
ance state, these channels must be set to either OFF or External. Figure 3-54
shows a schematic overview of the high-impedance control circuit.
Setup Menu
Side button
Control Condition
Event (Select Enable
or Disable)
Side button
Control Condition
Inhibit Level (Set the
inhibit level)
Side button
Control Condition
Channel Inhibit Con
trol
OK
3 71
