Table A 6: Nominal traits electrical characteristics (Cont.)
Characteristics
Inhibit function
Mode
Off
Internal
External
Both
Event input
Connector
Threshold level
Resolution
Input impedance
Turning point for event jump
Maximum input voltage
Polarity
Event output
Connector
Level
V
hi
V
lo
Delay time
Pulse width
Impedance
Inhibit input
Connector
Threshold level
Resolution
Input impedance
Maximum input voltage
Sync output
Connector
Pulse width
Impedance
