Nominal Traits

Table A 6: Nominal traits electrical characteristics
Characteristics
Operation mode
Repeat
Single
Step
Enhanced
Output pattern
Pattern length
Number of channels
Sequence
Number of blocks
DG2030 User Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This section describes the general characteristics of the DG2030. These are
divided into two main categories: Table A-6 Electrical Characteristics and
Table A-7 Mechanical Characteristics.
Description
Pattern data is repeatedly output. When a sequence is specified, patterns are repeated
according to the sequence order. The extended sequence functions such as trigger wait, event
jump, etc. are ignored in this mode.
Pattern data is output only once. When a sequence is specified, a trigger signal causes to
perform output according to the sequence order.
Pattern data are output based on the clock, not specified by clock source, but generated by
pressing the STEP/EVENT button on the front panel. This mode is the same as Repeat mode
except for the clock.
Pattern data is output completely according to a sequence. The all extended sequence
functions such as trigger wait, event jump, etc. are valid in this mode. This mode is same as
Repeat mode except for the extended sequence functions.
90 to 262144 points
Up to 4 for standard and 8 for option 01
Maximum 4000 steps
Maximum 256
Appendix A: Specifications
A 9
