Utility Menu

System Menu

Remote Port

GPIB Menu
Serial Menu
Power up Pause
Date and Time Setting
Remote Port
3 94
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This menu sets the instrument date, time, and the GPIB/serial port settings. The
GPIB and serial ports can be used for remote control and screen hardcopy. Select
the items to be changed using the up and down arrow buttons, and change the
value or the selection using the left and right arrow buttons or the general
purpose knob.
Figure 3 64: System menu
Set the port used for external remote control. Either the GPIB or the RS232C
can be selected.
Operation. Remote port setup
Bottom button Popup menu
System Select Remote Port with the up and down
arrow buttons.
Select the port with the left and right arrow
buttons.
Side button
