Routing

Command line
1. Log into the IX10 command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add a VRRP instance. For example:
(config)> add network vrrp VRRP_test
(config network vrrp VRRP_test)>
4. Enable the VRRP instance:
(config network vrrp VRRP_test)> enable true
(config network vrrp VRRP_test)>
5. Set the interface on which this VRRP instance should run:
a. Use the ? to determine available interfaces:
b. Set the interface, for example:
(config network vrrp VRRP_test)> interface /network/interface/eth
(config network vrrp VRRP_test)>
c. Repeat for additional interfaces.
6. Set the router ID. The Router ID must be the same on all VRRP devices that participate in the
same VRRP device pool. Allowed values are from 1 and 255, and it is configured to 50 by
default.
(config network vrrp VRRP_test)> router_id int
(config network vrrp VRRP_test)>
7. Set the priority for this router in the group. The router with the highest priority will be used as
the master router. If the master router fails, then the IP address of the virtual router is
mapped to the backup device with the next highest priority. If this device's actual IP address is
being used as the virtual IP address of the VRRP pool, then the priority of this device should be
set to 255 . Allowed values are from 1 and 255, and it is configured to 100 by default.
(config network vrrp VRRP_test)> priority int
(config network vrrp VRRP_test)>
8. (Optional) Set a password that will be used to authenticate this VRRP router with VRRP peers.
If the password length exceeds 8 characters, it will be truncated to 8 characters.
