Install SIM cards

To install SIM cards:

1. Use a Philips #0 driver to remove the SIM slot cover.

2. For high-vibration environments, apply a thin layer of dielectric grease to the SIM contacts.

Note If the IX10 device is used in an environment with high vibration levels, SIM card contact fretting may cause

unexpected SIM card failures. To protect the SIM cards, Digi strongly recommends that you apply a thin layer of dielectric

grease to the SIM contacts prior to installing the SIM cards. See

Grease over SIM Contacts

3. Insert the SIM card(s) into the SIM sockets. Insert the end of each SIM card with the chamfered corner positioned as

indicated. Push the SIM in until it clicks into place.

4. A er SIM cards are installed, use a Philips #0 driver to secure the SIM slot cover. Torque screw to 2 in lbs (225 mN m)

maximum.

Apply Dielectric Grease over SIM Contacts

Note Digi recommends using either the Loctite® LB 8423 Dielectric Grease or Synco Lube® Silicone Dielectric Grease.

1. Use a sheet of paper or cardboard over the area where you intend to work.

2. Use isopropyl alcohol and a cotton-tipped applicator to gently clean the SIM contacts. Using isopropyl alcohol requires a

well vented environment. Demineralized water can also be used as an alternative.

https://www.digi.com/resources/documentation/digidocs/90002399/#device/industrial/ix10/ix10-insert-sim-t.htm?TocPath=Digi%2520IX10%2520hardware%25...

for instructions.

Install SIM cards

Apply Dielectric Grease over SIM ContactsApply Dielectric

1/2

Need help?

Do you have a question about the IX10 and is the answer not in the manual?

Page 1 2. For high-vibration environments, apply a thin layer of dielectric grease to the SIM contacts. Note If the IX10 device is used in an environment with high vibration levels, SIM card contact fretting may cause unexpected SIM card failures. To protect the SIM cards, Digi strongly recommends that you apply a thin layer of dielectric grease to the SIM contacts prior to installing the SIM cards.
Page 2 4. When the dielectric grease has been applied, insert the SIM into the SIM slot as described above. SIM removal The IX10 has a PUSH-PUSH SIM connector. To insert, push each SIM in until it clicks, and repeat for removal. When you push to eject, the SIM ejects back out about 1/8 inch.
