What is a fault?
A fault is a message from the drive indicating an error or other exceptional (unwanted)
status. This could be caused by a fault within the converter or an external fault triggered, for
example, from the winding temperature monitor for the induction motor. The faults are
displayed and can be reported to a higher-level control system via PROFIdrive. In the
delivery condition, the message "Drive fault" is also sent to a relay output. Once you have
rectified the cause of the fault, you have to acknowledge the fault message.
What is an alarm?
An alarm is the response to a fault condition identified by the drive. It does not result in the
drive being switched off and does not have to be acknowledged. Alarms are "self
acknowledging", that is, they are reset automatically when the cause of the alarm has been
eliminated.
10.3

Overview of warnings and faults

If a fault occurs, the drive indicates the fault and/or alarm. Faults and alarms are listed in a
fault/alarm list, together with the following information:
● Fault/alarm number
● Standard drive response
● Description of the possible cause of the fault/alarm
● Description of the procedure for rectifying the problem
● Standard fault acknowledgement after it has been rectified
Note
List of faults and alarms
The list of faults and alarms is included on the customer DVD!
It also contains descriptions of possible fault responses (OFF1, OFF2, ...).
Note
Faults and alarms wired and preset at the factory
The faults and alarms described below have been wired specially for the cabinet units listed
in this document and preset via macro. In this way, the appropriate reaction is triggered by
the additional components in the cabinet unit when faults and alarms are signaled.
It is possible to reprogram the faults and alarms described, provided that the stated options
are not included in the scope of the equipment.
