Printronix P7000 Series Maintenance Manual page 93

Table 4. P7000 ASCII (Spool) Error Messages List
Displayed Message
ONLINE
CU TIMED OUT
PAP BAD TABLE*
PAP BSY TOO LNG*
Explanation
Controller Unit Timed Out.
The printer was not enabled
for one minute or more on a
coax interface.
Paper Bad Table. The paper
feed process on the
controller board has a
corrupted table.
Paper Busy Too Long.
Firmware error on the
controller board.
List Of Messages
Solution
Check cable connection and host
system. (Refer to line problem
determination procedures, as
recommended by the host system.)
1. Cycle power. Run the print job
again. If the message appears,
download the emulation software
again.
2. Cycle power. Run the print job
again. If the message appears,
replace the controller board.
Record the message and return it
with the defective board.
1. Cycle power. Run the print job
again. If the message appears,
download the emulation software
again (page 247).
2. Run the print job again. If the
message appears, power off the
printer. Remove the paper path or
pedestal top cover. Make sure
connectors P106 and P107 are
fully seated on the controller
board. Make sure the MPU cable,
the hammer bank logic cable, and
the hammer bank power cable
are undamaged and have good
connections. Replace as
necessary. (Refer to Appendix
A.)
3. Power on the printer. Run the
print job again. If the message
appears, replace the shuttle
frame assembly.
4. Power on the printer. Run the
print job again. If the message
appears, replace the controller
board. Record the message and
return it with the defective board.
93
