Printronix P7000 Series Maintenance Manual page 497

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
1 178908-001 178908-001
179804-001 179804-001
2 204956-001 204956-001
3 203251-001 203251-001
4 204458-001 204458-001
5 173818-001 173818-001
6 178899-001 178899-001
179802-001 179802-001
7 202721-901 202721-901
8 Ref
9 Ref
10 202716-001 202716-001
11 173726-001 173726-001
12 178058-001 178058-001
13 159398-001 159398-001
14 175726-901 175726-901
15 158446-001 158446-001
16 173530-001 173530-001
20 178918-001 178918-001
21 178913-001 178913-001
22 174392-001 174392-001
23 173864-001 173864-001
25 151527-905 151527-905
30 202705-901 202705-901
35 202720-901 202720-901
36 173830-001 173830-001
37 Ref
Description
Stacker Assembly, Power, Black
Stacker Assembly, Power, Gray
Washer, 5/16 X .200 X .030, Stainless Steel
Screw, Hex Skt Btn Hd, Zinc M3X8mm
Washer, Shim, .125 ID X .010 inch Thick
Timing Belt Tensioner Assy, Pwr Stkr
Deflector, Power Stacker, Black
Deflector, Power Stacker, Gray
Clip-On Bearing
Ref Screw, Torx, 6-32 x .25
Ref Screw, Shoulder, 10-32
Timing Belt
Shaft, Lift, Phase III
Pulley, Timing, Fairloc,12T
Pulley, Motor
Clip, Ground, Dimpled, Pwr Stkr
Motor Assembly, Power Stacker
Motor, Stepper, Power Stacker
Spring, Conforce, with Spool Assy
Field Kit, Tray, Cab, Rear, Black
Slide, Ball Bearing, Rear Tray
Tent, Paper, Power Stacker
Chain
Nylon Plug
Cable
Stacker Hardware Kit
Ref Screw, Shoulder, 8-32
List of Illustrations
Notes
Part of item 36
Part of item 36
Part of item 36
Part of item 36
Part of item 47
Elevator motor and paddle
motor
Paper puller motor
Mount outboard of shafts
Kit not illustrated
Part of item 36
497
