Integrated Print Management Sensor

Removal
1. Prepare the printer for maintenance (page 230).
2. Cabinet Models: Remove the paper path (page 303).
Pedestal Models: Remove the top cover assembly (page 281).
3. Remove the screw securing the Integrated Print Management sensor to
the base casting. (See page 350, items 28 and 29.)
4. Trace the sensor cable back to the controller board, noting the cable
routing and releasing the cable from restraints as necessary.
5. Disconnect the sensor cable connector from J122 on the controller board.
6. Lift the sensor and guide the sensor cable up and out of the base casting.
Installation
1. Reverse steps 2 through 6 of the removal procedure above.
2. Return the printer to normal operation (page 231).
