Printronix P7000 Series Maintenance Manual page 102

Chapter 3
Troubleshooting Display Messages
Table 4. P7000 ASCII (Spool) Error Messages List
Displayed Message
PWR SUPP VOLT*
QUEUE OVERRUN
RESTORING
BOOT CODE
REMOVE USED SPX
THEN PRESS ENTER
RIB INVLD CMD*
See User Manual
RIBBON AT END POINT
Change Ribbon
102
Explanation
Power Supply Voltage. The
power supply has failed.
In the CT twinax emulation,
the print buffer has
overflowed. Send a print job
to the printer.
Normal download
initialization message.
Status message: An SPX is
depleted because it has
successfully reprogrammed
the security key on the
controller board.
Ribbon Invalid Command.
Firmware error on the
controller board.
Integrated Print
Management System
software has determined
that the ribbon is out of ink.
Solution
Replace the power supply board.
1. If the message appears, replace
the CT board. Record the
message and return it with the
defective board.
2. Send a print job to the printer. If
the message appears, replace
the twinax data cable and the
twinax auto-termination cable
assembly ("Smart T").
No action required.
1. Remove the SPX from the Debug
Port.
2. Press the ENTER key. The
printer will reboot itself.
1. Cycle power. Run the print job
again. If the message appears,
download the emulation software
again.
2. Cycle power. Run the print job
again. If the message appears,
replace the controller board.
Record the message and return it
with the defective board.
Install a new ribbon.
