Appendix D
Stacker Operation

Loading And Starting The Power Stacker

1. Press the PAPER ADVANCE key and hand feed the paper down into the
paper throat of the stacker. Continue to advance the paper until it reaches
the paper tent (if installed) and feed three to five extra sheets into the
stacker. Make sure the paper passes through the paper throat of the
stacker. (Figure 72.)
2. Stack the extra pages on top of the wire paper tent (if installed), making
sure the paper bends with the natural fold. (Figure 72.)
3. Press the ON LINE key to put the printer in the online state. The stacker
elevator will return to the correct position for printing.
4. Check that the paper is still centered between the sides of the paper tent
(if installed).
5. Close the cabinet rear door.
6. If necessary, set Top Of Form. (Refer to the User's Manual .)
Figure 72. Stacking Paper on the Wire Paper Tent
462
ON LINE
PAPER
ADVANCE
A
A
