Printronix P7000 Series Maintenance Manual page 123

Table 5. P7000 H-Series (Spool) Error Messages List
Displayed Message
403:CLOSE PLATEN
404:FILE EXITS
ENABLE OVERWRITE
405:FLASH FULL
DELETE FILES
406:FLASH FULL
OPTIMIZE&REBOOT
Explanation
The platen lever is open.
The printer has deleted the
previous program from flash
memory and is loading the
new program into flash
memory.
The printer requires more
flash memory to run the
downloaded program.
The printer requires more
flash memory to run the
downloaded program.
List Of Messages
Solution
1. Load paper. Close the forms
thickness lever.
2. Power off the printer. Remove the
paper path or pedestal top cover.
Disconnect connector P107 from
the controller board. Check
continuity of the platen interlock
switch from P107/PLO to the
switch. Replace the switch
assembly if it fails the continuity
test. (Refer to Appendix A, Switch
Assembly, Platen Interlock.)
3. With the forms thickness lever
closed (position A), hold a 0.011
inch (0.028 cm) feeler gauge
between the switch and the body
of the forms thickness lever,
gently press down on the switch,
and tighten the two screws.
4. Check and adjust the platen open
belt. Replace the belt if it is
damaged.
5. Disconnect connector P106 from
the controller board. Check the
resistance of connector P106/
PLAT M. (See the Main Wire
Harness Test Tables in Appendix
A.) Replace the platen open
motor if it fails the resistance test.
6. Run a print test. If the message
appears, replace the controller
board. Record the message and
return it with the defective board.
No action required.
Delete files, add flash memory, or use
a smaller emulation program.
Add flash memory or use a smaller
emulation program.
