Table 4. P7000 ASCII (Spool) Error Messages List
Displayed Message
LOAD PAPER
LOADING PROGRAM
FROM PORT XX%
LOADING PROGRAM
INTO FLASH
Explanation
The printer is out of paper.
Status message: the new
emulation program is
loading into printer RAM.
XX% indicates how much of
the program has loaded.
The printer has deleted the
previous program from flash
memory and is loading the
new program into flash
memory.
List Of Messages
Solution
1. Load paper. Press CLEAR. If
message does not clear, go to
the next step.
2. Check for black or colored
backing on the paper being used
in printer. The paper out detector
is optical and may not detect
paper with a black or dark
backing facing the detector. Try
paper with a white or light back. If
paper with white/light back works
and black/dark paper does not,
replace the paper detector switch
with the optional black back forms
switch assembly. (See page 354,
item 3.)
3. Power off the printer. Remove the
paper path or pedestal top cover.
Remove the barrier shield
(cabinet model) or the barrier
shield and paper guide (pedestal
model). Check that the paper
detector switch assembly is
securely mounted in its bracket.
4. Check that connector P106/PMD
is fully seated in connector J106
on the controller board.
5. Load paper. Power on the printer.
Replace the paper detector
switch assembly if message
appears.
6. Load paper. Power on the printer.
Replace the controller board if
message appears. Record the
message and return it with the
defective board.
No action required.
No action required.
