Printronix P7000 Series Maintenance Manual page 351

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
1 Ref
2 Ref
3 150957-901 150957-901
4 Ref
5 174968-001 174968-001
6 Ref
7 112657-901 112657-901
8 Ref
9 Ref
10 Ref
11 179334-901 179334-901
12 Ref
13 Ref
14 Ref
15 178705-901 178705-901
16 Ref
17 Ref
18 Ref
19 Ref
20 Ref
21 150703-902 150703-902
22 Ref
23 141516-901 141516-901
24 153488-001 153488-001
25 177558-001 177558-001
26 Ref
Description
Ref Setscrew (2)
Ref Bracket, Platen (2)
Ironer Assembly, Reverse Paper Feed
Ref Screw, Thread-forming (3)
Ironer Bracket/Plate Field Kit
Ref Plate, Ironer
Platen Assembly
Ref Washer, Flat (2)
Ref Screw (2)
Ref Washer, Flat #4 (2)
Field Kit, Switch Assy, w/Bracket
Ref Screw, Socket Cap, 6-32x.75
Ref Washer
Ref Nut
Platen Stop Lever Kit
Ref Spring, Extension 1.12L
Ref Link, Spring
Ref Bearing, Nylon .376
Ref Bracket, Switch Mount
Ref Wear Saddle, Platen (2)
Platen Pulley, Drive
Ref Screw, Socket Cap, 6-32x.44
Belt, Timing, .080 Pitch, .312 Wide
Field Kit, Covers
Platen Hardware Kit
Ref Platen Washer
Illustrations of Printer Components
Notes
Part of item 25
Part of item 25
All except ZTP printers
6-32x.25
Part of item 5
Part of item 25
Part of item 11
Part of item 11
Includes items 9, 10, 19
Part of item 15
Part of item 15
Part of item 15
Includes items 12, 13, 14
Part of item 25
Part of item 25
Part of item 25
Part of item 11
Part of item 25
Part of item 21
Platen Open Belt
Platen Open Belt Cover
shown
Includes items 1, 2, 8, 16,
17, 18, 20, 26, 30
Part of item 25
