Chapter 5
Replacement Procedures

Paper Ironer

WARNING
Over time, the upper edge of the paper ironer can become sharp. To
avoid cutting yourself, handle the paper ironer on the sides.
Removal
1. Prepare the printer for maintenance (page 230).
2. Remove the shuttle frame assembly (page 321).
3. Move the forms thickness lever to the open position.
4. Push the ends of the paper ironer toward the rear of the printer,
disengage the tabs, then lift it up and out (page 350, item 3).
5. On models P7000HD, P7X06H, P7X08H, P7x15, and P7220, remove the
auxiliary paper ironer, which is directly in front of the standard paper
ironer.
Installation
NOTE: The black tape on the standard paper ironer faces toward the rear of
1. Position the paper ironer so the black tape is on the side that faces the
rear of the printer, towards the paper detector switch assembly. (See
page 350, item 3.)
2. Push the paper ironer down into the slots until the tabs engage.
3. On models P7000HD, P7X06H, P7X08H, P7x15, and P7220, install the
auxiliary paper ironer in front of the standard paper ironer. (See also the
note on page 350, next to item 27.) Make sure the tabs on both paper
ironers are firmly engaged.
4. Install the shuttle frame assembly (page 321).
5. Return the printer to normal operation (page 231).
302
the printer and toward the paper detector switch assembly.
