Printronix P7000 Series Maintenance Manual page 551

Europe,
Mideast,
Americas
and Africa
Item and Asia/
(EMEA)
No. Pacific
Part No.
Part No.
(RoHS
Compliant)
1 Ref
2 Ref
3 Ref
4 174968-001 174968-001
5 Ref
6 112657-901 112657-901
7 Ref
8 Ref
9 Ref
10 179334-901 179334-901
11 Ref
12 Ref
13 Ref
14 178705-901 178705-901
15 Ref
16 Ref
17 Ref
18 Ref
19 Ref
20 150703-902 150703-902
21 Ref
22 141516-901 141516-901
23 153488-001 153488-001
24 177558-001 177558-001
25 Ref
26 179526-901 179526-901
27 Ref
Description
Ref Setscrew (2)
Ref Bracket, Platen (2)
Ref Screw, Thread-forming (3)
Ironer Bracket/Plate Field Kit
Ref Plate, Ironer
Platen Assembly
Ref Washer, Flat (2)
Ref Screw (2)
Ref Washer, Flat #4 (2)
Field Kit, Switch Assy, w/Bracket
Ref Screw, Socket Cap, 6-32x.75
Ref Washer
Ref Nut
Platen Stop Lever Kit
Ref Spring, Extension 1.12L
Ref Link, Spring
Ref Bearing, Nylon .376
Ref Bracket, Switch Mount
Ref Wear Saddle, Platen (2)
Platen Pulley, Drive
Ref Screw, Socket Cap, 6-32x.44
Belt, Timing, .080 Pitch, .312 Wide
Field Kit, Covers
Platen Hardware Kit
Ref Platen Washer
Sensor Assembly, Integrated Print
Management System/Barcode
Ref Screw
Illustrations of ZTP Components
Notes
Part of item 24
Part of item 24
6-32x.25
Part of item 4
Part of item 24
Part of item 10
Part of item 10
Includes items 8, 9, 18
Part of item 14
Part of item 14
Part of item 14
Includes items 11, 12, 13
Part of item 24
Part of item 24
Part of item 24
Part of item 10
Part of item 24
Part of item 20
Platen Open Belt
Platen Open Belt Cover
shown
Includes items 1, 2, 7, 15,
16, 17, 19, 25
Part of item 24
