Control Panel Assembly - Printronix P7000 Series Maintenance Manual

Chapter 5
Replacement Procedures

Control Panel Assembly

NOTE: The procedure for removing and installing the control panel is the
Removal
1. Prepare the printer for maintenance (page 230).
2. Open the printer cover.
3. Disconnect the RJ-11 connector P310 from J2 on the back of the control
panel. (See page 332, item 2.)
4. Remove the two screws securing the control panel to the panel bracket.
(See page 332, items 1 and 11.)
5. Remove the control panel assembly from the panel bracket.
Installation
1. Engage the slot on the bottom of the control panel on the bottom edge of
the panel bracket cutout. (See page 332, items 1 and 11.)
2. Align the holes on the top rear of the control panel with the holes in the
upper edge of the panel bracket, and install the two mounting screws.
3. Connect RJ-11 connector P310 to connector J2 on the rear of the control
panel.
4. Return the printer to normal operation (page 231).
276
same for cabinet and pedestal model printers.
