Symptom
Stacker does not stack
properly
Stacker elevator does not
move
Stacker elevator moves by
itself
Table 6. General Symptom List
1. Check for and remove obstructions preventing elevator
movement.
2. Check for misaligned stacker rails. Adjust the stacker rails
if they are not vertical and parallel.
3. Power on the printer. Operate the power stacker. (Refer to
the Operator's Guide .) While the stacker is operating,
check that:
a) all motors are operating
b) the paddles are rotating
c) the elevator moves smoothly and without obstruction
d) the timing belts are undamaged and the belt pulleys are
not slipping
e) the extension springs are attached and undamaged (not
bent or stretched)
f) the drive rollers are not damaged
g) the constant force springs are tightly mounted and
undamaged
Tighten pulley setscrews and/or replace damaged
components as necessary.
4. Check the stacker limit switches. (See page 196.) If the
limit switches are OK, go to the next step.
5. Check the stacker motors. (See page 197.) If the stacker
motors are OK, go to the next step.
6. Remove the paper path. Disconnect stacker cables from
the controller board, stacker assembly, and the stacker
control panel (see Figure 79, page 472). Check cables for
cuts, breaks, or damaged pins. Check continuity of cables.
(See Appendix A.) Replace any cable that is damaged or
fails continuity test. Reconnect all stacker cables to the
controller board, stacker, and stacker control panel.
See "Stacker does not stack properly"
1. Power off the printer. Inspect all stacker LEDs for dust,
chaff, or dirt. (See Figure 105 through Figure 107, page
500 through page 504.) Clean the stacker LEDs and the
sight tubes in the LED mounts.
2. Power on the printer. If the stacker elevator moves by
itself, replace the stacker LEDs. (See Figure 105 through
Figure 107, page 500 through page 504.)
General Symptom List
Solution
195
